Architecture: Containers, VMs, and Hypervisors

What runs Kubernetes (and why it matters)

Goal for this session

By the end of this deck, you should be able to answer:

  • Where does Kubernetes sit in the stack?
  • What is the difference between containers and VMs?
  • What does a hypervisor do?
  • Why are hypervisors still used everywhere (cloud, embedded, automotive)?

Where we are in the course

You already know:

  • App + database
  • Containers
  • Compose
  • CI automation

Now we zoom out:

  • Orchestration (Kubernetes)
  • The platform under the cluster (virtualization)

The full stack view

Typical production stack:

App → Container → Pod → Node → VM → Hypervisor → Hardware

Kubernetes is not “the bottom”. It runs on top of an operating system.

Container recap

A container is:

  • A process (or a set of processes)
  • Isolated using Linux kernel features
  • Packaged with a filesystem and dependencies

Key idea:

  • Containers share the same kernel.

Container isolation is real, but different

Containers isolate:

  • filesystem
  • process tree
  • networking
  • resource limits (CPU, memory)

But they do not change this:

  • Same kernel for everyone
  • Kernel bugs affect everyone

What is a VM?

A Virtual Machine is:

  • A full operating system (its own kernel)
  • Running as a guest on a hypervisor
  • With virtual CPU, memory, storage, and devices

Key idea:

  • VMs isolate at the kernel boundary.

Containers vs VMs (quick comparison)

Containers:

  • fast startup
  • lightweight
  • share the host kernel

VMs:

  • stronger isolation
  • different kernels possible
  • heavier, but very flexible

Neither is “better”. They solve different problems.

What is a hypervisor?

A hypervisor is the software layer that:

  • shares hardware between VMs
  • provides virtual CPUs and devices
  • enforces isolation between guests
  • manages scheduling and memory

Think: “traffic controller” for virtual machines.

Type 1 vs Type 2 (high level)

Type 1 (bare metal):

  • runs directly on hardware
  • common in servers and embedded

Type 2 (hosted):

  • runs as an app on a host OS
  • common on laptops (VirtualBox)

We care mostly about Type 1 in production.

Where Kubernetes nodes usually run

In most clouds:

  • Each Kubernetes node is a VM
  • Your Pods run inside containers
  • Those containers run on a kernel inside that VM

So the isolation boundary is often:

Pod → container → VM → hypervisor → hardware

Why cloud providers love VMs

VMs make cloud operations easier:

  • strong tenant isolation
  • per-customer quotas and limits
  • live migration and maintenance workflows
  • predictable billing units

Even when you use containers, the cloud is still virtualized.

Why virtualization matters in automotive

In automotive systems you often need:

  • mixed-criticality workloads
  • isolation between safety and non-safety domains
  • secure separation of supplier components
  • predictable scheduling and resource control

A hypervisor lets multiple OSes share one SoC safely.

Embedded and edge

At the edge, virtualization helps when you need:

  • multiple workloads on limited hardware
  • OTA updates without bricking the system
  • isolation between apps from different teams
  • long-lived systems with strict stability needs

It is not only a data center story.

Security view: isolation boundaries

When you choose an isolation boundary, ask:

  • what can escape?
  • what is the blast radius?
  • who controls the kernel?

Typical boundaries (weak → strong):

process → container → VM → hardware partition

Performance view

Virtualization used to be “slow”. Modern hardware support changed that.

Today, virtualization is often:

  • close to native performance
  • predictable and measurable
  • good enough for production at scale

The tradeoff is mostly operational, not raw speed.

Where this connects to our labs

In our labs, you will notice:

  • your cluster is “somewhere”
  • it has nodes
  • nodes have CPU and memory constraints
  • failures happen at different layers

Good debugging starts by asking: “What layer am I in right now?”

Observability by layer

When something fails, pick the layer:

  • App logs (inside container)
  • Pod / Deployment status (Kubernetes)
  • Node resources (CPU, memory pressure)
  • VM / host limits (virtualization)
  • Physical hardware / network

The symptom shows up at one layer. The cause may be below it.

Mini discussion

Pick one:

  • When would you choose a VM over a container?
  • What is one risk containers do not solve?
  • Why might an automotive platform choose a hypervisor?

We want reasoning, not buzzwords.

What I care about today

I am not grading “hypervisor facts”.

I care that you can:

  • place each technology in the stack
  • explain why it exists
  • name the tradeoff it makes
  • identify what it does not solve

Back to the lab

Next, we will:

  • deploy to Kubernetes
  • break things
  • debug with get / describe / logs

Keep the stack in mind. It will make debugging easier.
